TURQUOISE
Anadolu Isuzu’s tested and trusted medium-size coach is now powered by the new Euro 2 Isuzu engine. Isuzu common rail turbo diesel engine produces 175 horsepower at 2600 rpm.
Turquoise offers a pleasant journey to the driver and the passengers with its stylish interior design and with its wide spectrum of comfort equipments. Combining the advantages of a minibus and a full-size coach in a smart “midi” concept, Turquoise becomes an ideal partner for short and medium-haul journeys, local transportation, panoramic tours and excursions.
Technical Features
| Maximum Length | 7720 |
| Maximum Width | 2320 |
| Maximum Height | 3330 |
| Wheelbase | 3815 |
| Front Overhang | 1673 |
| Rear Overhang | 2232 |
| Front Track Width | 1904 |
| Rear Track Width | 1650 |
| Inner Height | 1910 |
| Gross Vehicle Weight | 10400 |
| Curb Weight | 6130-7770 |
| Front Axle Capacity | 4000 |
| Rear Axle Capacity | 6400 |
| Model | 4HK1-TCC (Euro 2) |
| Type | Commonrail Turbo Diesel Intercooler |
| Cylinders | 4 |
| Displacement (cc) | 5193 |
| Maximum Power (PS/rpm) | 175 / 2600 |
| Maximum Torque (Nm/rpm (Kgm/rpm) | (500 /1600-2600) |
| Clutch | Hydraulic Actuated With Diaphram Spring and Single Dry Plate |
| Model | ISUZU MZZ-6U |
| Number of Gears, Type | 6 Forward, 1 Reverse, Overdrive |
| Final Gear Ratio | 4,777 |
| Steering System | Hydraulic, Tilt and Telescopic |
| Minimum Turning Radius (mm) | 7610 |
| Gradeability (%) | 38,7 |
| Tyres | 235/75 R17,5 |
| Front | Parabolic Steel Alloy Leaf Springs |
| Rear | Air Suspension |
| Front / Rear | Disc / Disc |
| System | Full Air Brake System with ABS, Dual Circuit, Auto-adjusted |
| Parking Brake | Air Actuated, Operating on Rear Axle |
| Auxiliary Brake | Vacuum Assisted Exhaust Brake and Retarder |
| Fuel Tank Capacity (lt) | 190 |
| Fuel Tank Cap Lock | S |
| Luggage Capacity (m3) | 4,2 |
| Carpet Covering | S |
| Luggage Compartment Lighting | S |
| Central Locking System | Opt |
| Interior Luggage Racks | S |
| Electrical System | 24V – 100A |
| Nominal Voltage | 24V |
| Battery | 24V (2x12V)-125 Ah |
| Starter Engine | 24V – 4,5kW |
| Passenger Capacity | From (26 + c + d) To (33 + c + d) |
Equipments
| Pre-heater | S |
| Air-blowing Type Heater (Front) | S |
| Other | Convector Heater |
| Air Conditioner | Digital Air Conditioner |
| A/C Dashboard Unit For Driver | S |
| Air Conditioner With Heater | Opt |
| Tropical A/C | Opt |
| Cruise Control | S |
| Speed Limitor | S |
| Tachograph | Digital Tachograph (S) / MTCO (Opt) |
| Retarder | S |
| ABS | S |
| ASR | S |
| Parking Sensor | S |
| Immobiliser | S |
| Fire Sensor And Warning System In Engine Compartment | Opt |
| Roof Emergency Exit & Ventilation Hatch | S |
| Side Stripe Stickers | Opt |
| Metallic Colour | Opt |
| Front Door | Single Wing, Pneumatic, Outward Swing |
| Rear Door | Single Wing, Pneumatic, Outward Swing |
| Remote Control | S |
| Passenger Window | Single Piece, Tinted |
| Single Glazing | Opt |
| Double Glazing | S |
| Ski Box Brackets and Sockets | Opt |
| Towing Hook | S (Front) |
| Extra third stop lamp | S |
| Fog Lamp | S |
| Reverse Gear Warning Beeper | S |
| Driver’s Seat | Ergonomic, Air Operated, Adjustable |
| Overhead Locker For Driver | S |
| Driver’s Window | Manuel Sliding, Anti-mist Heater |
| Front Door Window | Anti-mist Heater |
| Windscreen Blind | S (Electrically Controlled Optional) |
| Electrically Controlled Side Rear Mirrors | S |
| Heated Long Arm Mirrors | S |
| Close-proximity Exterior Mirror | S |
| Crew Seat | S |
| Overhead Locker For Crew | S |
| Seat Upholstery | Fabric (S) / Leather (Opt) |
| Service Sets (Hostess Button, Reading Lamps) | S |
| Reclining | S |
| Side Sliding | S |
| Footrests | Opt |
| Armrests | Aisle Side (S) / Window Side (Opt) |
| Seat Back Magazine Net | S |
| Seat Back Tray | S |
| Safety Belts | 2 Points (S) / 3 Points (Opt) |
| Ceiling Upholstery | Fabric |
| Side Wall Upholstery | Fabric |
| Floor Covering | Carpet on Vinyl Floor |
| Interior Lighting | Continuous on Ceiling |
| Reading Lamps For Passenger Seats | S |
| Radio & CD Player | S |
| Radio & DVD Player (With MP3) | Opt |
| Speaker | S |
| Headphone Outputs For Passanger Seats | Opt |
| Microphone & Amplifier | S |
| Monitor / LCD | Opt |
| TV tuner | Opt |
| Refrigerator (Front or Rear) | Opt |
| Water Boiler (Tea/Coffee Set) | Opt |
