NOVOCITI VOLT
Anadolu Isuzu’s first 8-meter length EV public transportation bus, NovoCiti VOLT has TM4 electric motor which produces 255 kW. NovoCiti VOLT offers efficiency, high-manoeuvrability and a barrier-free transportation solution for operators and municipalities, above all promises a clean future.
Designed and produced by Anadolu Isuzu, NovoCiti VOLT will bring zero emission and lowered noise to the cities. With the astonishing exterior design, 8-meter length, low maintenance cost, long range and new features, NovoCiti VOLT provides latest technology and best maneuverability amongst electric vehicles.
Technical Features
| Maximum Length | 7957, 8010 |
| Maximum Width | 2463 |
| Maximum Height | 3250 |
| Wheelbase | 4259 |
| Front Overhang | 1947 |
| Rear Overhang | 2425 |
| Front Track Width | 1753, 1804 |
| Gross Vehicle Weight | 11600 |
| Drive Type | Battery Electric Vehicle (BEV) |
| Engine Type | Electric Traction Motor – Direct Drive |
| Engine Model | TM4 Sumo MD |
| Peak Power (kW) | 255 kW |
| Peak Torque (Nm) | 2355 Nm |
| Operating Voltage | Option-1: 600 V Option-2: 600 V |
| Compliant with ECE-100 Revision 2 | Option-1: Yes Option-2: Yes |
| Battery Type | Option-1: Lithium Ion (LFP Hybrid) Option-2: Lithium Ion (LFP Hybrid) |
| Battery Cooling and Heating Systems | Option-1: S Option-2: S |
| Battery Capacity | Option-1: 211 kWh Option-2: 269 kWh |
| Batteries Location | Option-1: Top of the vehicle Option-2: Top of the vehicle |
| Range (km) | Option-1: Up to 300 km ( w/o AC) Up to 200 km (w AC) Option-2: Up to 350 km ( w/o AC) Up to 250 km (w AC) |
| Battery Warranty | Option-1: 8 Years* Option-2: 8 Years* |
| Charging Type | Option-1: AC / DC Type 2 (CCS Type 2) Option-2: AC / DC Type 2 (CCS Type 2) |
| On Board Charger | Option-1: Opt Option-2: Opt |
| Power | Option-1: AC Plug in – 22 kW DC Plug in – 150 kW Option-2: AC Plug in – 22 kW DC Plug in – 150 kW |
| Charging Time | Option-1: Up to 2h With DC Plug in Up to 8.5h with AC Plug in Option-2: Up to 2,5h With DC Plug in Up to 11h with AC Plug in |
| Body Type | Monocoque, Full Body Cataphoresis Coating |
| Front Axle | Air Suspansion, 2 Air Bellows, 2 Hydraulic Shock Absorbers |
| Rear Axle | Air Suspansion, 2 Air Bellows, 2 Hydraulic Shock Absorbers |
| Kneeling System | S (ELC) |
| Front / Rear | Disc / Disc |
| System | Full Air Brake System With ABS (EBS), ESP, Dual Circuit, Electronical Actuated |
| Parking Brake | Air Actuated, Operating on Rear Axle |
| Auxiliary Brake | Motor Reverse Retarding and Braking Regeneration |
| System | Electric hydraulic power steering |
| Tyre Sizes | 245/70 R17.5 |
| Maximum Passenger Capacity | Option-1: 52 Passengers Option-2: 46 Passengers |
| Standard Layout | Option-1: 25 Seated (4 foldable) + 26 Standing Option-2: 25 Seated (4 foldable) + 20 Standing |
| Layout with Wheelchair | Option-1: 21 Seated + 1 Wheelchair + 26 Standing Option-2: 21 Seated + 1 Wheelchair + 20 Standing |
Equipments
| Air Conditioning | S |
| Heating | S |
| Number Of Service Doors | 2 Doors |
| Type of Service Doors | Front: Single Wing, Pneumatic, Inward Swing. Rear: Double Wings, Pneumatic, Outward Swing |
| Wheelchair Ramp | Manual (S) |
| Tachograph | Smart |
| Parking Sensor | S |
| Fire Extinguisher | Opt |
| Engie Compartment Fire Detection System | S |
| Engine Compartment Fire Detection and Automatic Fire Supression System | S |
| Fog Lamps | S |
| BSB (Bus Stop Brake) | S |
| HillHolder | S |
| Day Time Running Lamps (DRL) | S |
| Locking System | S |
| Driver’s Cabin | Semi Glass (Opt), Full Glass (Opt) |
| Ticket Validator Preperation | Opt |
| USB Charger for Driver | S |
| Rear View Camera | Opt |
| Front View Camera | Opt |
| Interior Camera | Opt |
| Exterior Camera | Opt |
| Recording Device Preperation | Opt |
| Recording Device (DVR) | Opt |
| Interior Ceiling Lighting | S (Continuous, LED) |
| Stop Buttons & Signboard | S |
| Digital Destination Display | Front (S), Rear (S) |
| Radio System | Radio, USB, SD Card (S) |
| Announcement System | S (Swan type mic.) |
| Speaker | S |
