KENDO 12.3
Anadolu Isuzu’s 12.3 meter Intercity, Kendo 12.3, has Euro 6 Cummins engine which produces 370 HP at 2100 rpm.
Kendo is a 12.3 m, service, school and short distance intercity transportation vehicle and Anadolu Isuzu’s first bus family within its segment. It is one of the very first members with the new design language which is digital, black contoured face with split design headlights and dynamic signal lamps. Dramatic body, new dashboard and UX design supports this new statement. With its capacity up to 59 seats, Kendo 12.3 offers a high level of comfort to its passengers.
Technical Features
| Maximum Length | 12305 |
| Maximum Width | 2550 |
| Maximum Height | 3440 |
| Wheelbase | 6265 |
| Front Overhang | 2260 |
| Rear Overhang | 3380 |
| Gross Vehicle Weight | 19000 |
| Model | Cummins L9E6D370B |
| Type | Diesel Turbocharged |
| Cylinders | 6 |
| Displacement (cc) | 8900 |
| Maximum Power (kw(HP)/rpm) | 276kW (370) / 2100 rpm |
| Maximum Torque (Nm/rpm) | 1600 Nm / 1400 rpm |
| Exhaust Gas Emission Class | Euro VI OBD-D |
| Model | ZF 6AP 1700B |
| Type | Automatic, Overdrive |
| Number of Gears | 6 Forward, 1 Reverse |
| Steering System | Hydraulic and Adjustable Dashboard and Steering Wheel Column in Height and Inclination |
| Tyres | 295/80 R22.5 |
| Front | Independent Air Suspansion, 2 Air Bellows, 2 Hydraulic Shock Absorbers |
| Rear | Air Suspension – 4 Air Bellows – 4 Hydraulic Shock Absorber |
| Front / Rear | Disc / Disc |
| System | Full Air Brake System With ABS and EBS, Dual Circuit, Auto-Adjusted |
| Parking Brake | Air Actuated, Operating on Rear Axle |
| Auxiliary Brake | Retarder – Integrated with Transmission |
| Fuel Tank Capacity (lt) | 350 |
| Adblue Tank (lt) | 43 |
| Luggage Capacity (m3) | 5.9 m3 (w/o Ramp) / 5.3 m3 (w Ramp) |
| Central Locking System | Single Lock Manual (S), Electrically Controlled (Opt) |
| Interior Luggage Racks | Opt |
Battery 24V (2x12V) -240 Ah
| Standard Seat Layout | 59 Seated + 1 Standing |
| Optional Seat Layouts | 55 Seated (4 Foldable Seated ) + 1 Standing |
| Seat Layouts With Wheelchair | 55 Seated + 1 Wheelchair (4 Folded Seated) + 1 Standing |
Equipments
| Pre-heater | S |
| Convector Heater (Panel Radiator) | S |
| Digital Air Conditioner | Opt |
| Dashboard A/C | S |
| Speed Limitor | S |
| Tachograph | S |
| Alcoholmeter and Preparation | Opt |
| ABS | S |
| ASR | S |
| EBS | S |
| ESC/ESP | S |
| AEBS | Opt |
| LDWS | Opt |
| Retarder | S (Intarder) |
| Parking Sensor | S |
| Fire Extinguisher | Opt |
| Engine Compartment Fire Detection System | S |
| Engine Compartment Fire Detection and Automatic Fire Supression System | Opt |
| Roof Emergency Exit and Ventilation Hatch | S |
| Fog Lamp | Opt |
| Day Time Running Lamps (DRL) | S |
| Reverse Gear Warning Beeper | S |
| Rear View Camera | Opt |
| Metallic Paint | Opt |
| Towing Device | S |
| Mechanical Coupling Device & Socket | Opt |
| Number Of Service Doors | 2 |
| Type of Service Doors | Front: Single Wing Outwards Opening Rear : Double wings Outwards Opening |
| Remote Control | S |
| Wheelchair Lift or Preparation | Opt |
| Type | Single Piece, Tinted |
| Layers of Glass | Single Glazed with Slider (S), Double Glazed (Opt) |
| Driver’s Seat | With Air Spings, Adjustable, 3-Point Safety Belt, Safety belt Alarmed System (S), Heated Seat (Opt) |
| Windscreen Blind | Manual (S), Electrically Controlled (Opt) |
| Driver’s Window | Single Glazed, Sliding with Heater (S), Electrically Controlled (Opt) |
| Front Service Door | Single Glazed, Heated (S) |
| Cloth (Fabric) Upholstery | Fabric |
| Reclining | Opt |
| Sliding (Aisle) | Opt |
| Footrests | Opt |
| Seat Back Tray | Opt |
| Armrests | S (Fix Type – Aisle Side), Opt (Window Side), Opt (Foldable Type) |
| Safety Belts | S (2-Points), Opt (3-Points) |
| USB on Seats | Opt |
| Ceiling Upholstery | Fabric |
| Side Wall Upholstery | Fabric |
| Floor Cover Material | Vinyl |
| Overhead Multi-Sets (Crew Call Button, Reading Lamps) | S |
| Curtains (Passenger Windows) | S |
| Refregerator | Opt** |
| Tea/Caffee Unit | Opt** |
| Interior Camera and Camera Screen on Dashboard | Opt |
| Entertainment System | Opt (7inch Touch Multimedia with USB/AUX/FM/AM/(RDS) / Bluetooth/ Handfree) |
| Speaker | S |
| Microphone & Amplifier | Opt |
| Digital Clock | S |
| School Bus Signs | Opt (Front and Rear) |
| Destination Board | Opt (Front, Right, Rear) |
| LCD Screen (Passenger Compartment) | Opt |
