CITIPORT 12
Ideal solution for public transportation. The bus offers a comfortable and safe journey to the passengers with its spacious internal layout.
Taking into account the actual needs of the major metropolises and municipalities, Anadolu Isuzu’s new 12 meter public transportation bus has been designed in a way to meet the concept of the “ideal solution for public transportation”. Citiport has an attractive exterior view thanks to its outstanding and unique design.
Technical Features
| Maximum Length | 12030 |
| Maximum Width | 2550 |
| Maximum Height | 3136 (Including A/C unit) |
| Wheelbase | 5850 |
| Front Overhang | 2700 |
| Rear Overhang | 3480 |
| Front Track Width | 2152 |
| Rear Track Width | 1872 |
| Gross Vehicle Weight | 17900 |
| Model | CUMMINS ISB6.7E5300 (Euro 5) |
| Type | Dizel Commonrail Turbo Compressor |
| Number of Cylinders | 6 |
| Displacement (cm3) | 6700 |
| Maksimum güç (HP / rpm) | 289 / 2300 |
| Maksimum Tork (Nm / rpm) | 1087 /1285 |
| Model | ZF 6 AP 1200B (Automatic) |
| Number of Gears, Type | 6 Forward, 1 Reverse, Overdrive, 3 Levels With Manual and Foot Controlled Retarder Function |
| Front | Independent Air Suspension – 2 Air Bellows (ECAS) |
| Rear | Air Suspension – 4 Air Bellows (ECAS) |
| Front / Rear | Disc / Disc |
| System | Full Air Brake System With EBS, (Automatic Oil, Water Seperator System – Opt), (Oil, water separator system provides extend-life your brake systems) |
| Parking Brake | Air Actuated, Acted On Rear Axle |
| Auxiliary Brake | Intarder |
| Passenger Capacity (Max.) | 107 passangers |
| Standard | 27 (24 Fixed + 3 Folding) Passenger Seats + 1 (Maximum 79 Standing Passengers When Folding Seats Are Closed) |
| Optional | 31 (28 Fixed + 3 Folding) Passenger Seats + 1 (Maximum 72 Standing Passengers When Folding Seats Are Closed) |
| Fuel Tank Capacity (lt) | 300 |
| System Voltage | 24 V |
| Battery | 2 x 240 Ah |
| Steering System | Hydraulic |
| Tyres | 275/70 R22,5 |
Equipments
| Digital Tachograph | S |
| Multiplex System | S |
| Pre-heater | Opt |
| Heater (Front/Middle/Rear) | S |
| Digital Air Conditioner | S |
| A/C with Heater | Opt |
| Roof Emergency Hatch & Ventilation Hatch | S |
| Parking Sensor | S |
| Reverse Gear Warning Beeper | S |
| Interior Camera | S (DVR recording device) |
| Exterior Camera | S (At the Rear and On Side Rear View Mirrors) |
| Retarder | S |
| ABS | S (EBS) |
| ASR | S (EBS) |
| Engine Room Fire Detector and Warning System | S |
| Auto Fire Extinguisher for Engine Room | Opt |
| Automatic Engine Oil Refilling System | Opt |
| Diesel Exhaust Emission Fluid Heater | S |
| Speed Limitor | S |
| Electrically Controlled Side View Mirrors | S |
| Heated Side View Mirrors | S |
| Daytime Running Lamps (DRL) | S |
| Front and Rear Fog Lamps | S |
| Towing Device | S |
| Metallic Paint | Opt |
| Number of Service Doors | 3 Doors |
| Type of Service Doors | Double Wings, Pneumatic, Inward Swing |
| Disabled Passenger Access | Ramp for Middle Door & Kneeling System |
| Remote Control for Front Door | S |
| Windscreen | Single Piece Laminated |
| Driver’s Window | With Resistance Heater, Electrical Contol |
| Blind | Electrical Control For Windscreen Roller Blind |
| Passenger Windows | Single Piece, Non-sliding |
| Single Glazing | S |
| Hinged window | 1/4 Hinged Passenger Windows |
| Steering | Adjustable Steering Wheel Integrated With The Display Cluster |
| Driver’s Seat | Air actuated, Adjustable, With Headrest |
| Driver’s Cabin | S (Semi Closed) |
| Driver Overhead Cabinet | S (Locker) |
| Ticket Box Pre-arrangement | Opt |
| Seat Material | Cloth Ped On Plastic |
| Interior Lining (Ceiling) | Formica |
| Stop Sign (Interior) | S |
| Info Panel for Passengers | Front (S), Rear (Opt) |
| Digital Destination Indicators | Rounding LED-type Headsign (Front and Side) (S), Rear Indicator Panel (S), Colored Headsign (Not Rounding) (Opt) |
| High-Drive Mode | S |
| Announcement System Preperation | S (Interior / Exterior) |
| LCD Screen | “S (1 Unit, Front) |
| Digital Clock | S |
